√ Uniform insulation thickness for easy stripping and cutting,Passed FT-2 flame test
√ Internal wiring of appliances. Tags may indicate the following: 600 V Peak - For Electronic Use Only.
√ Rating: 80 deg C, 300 Vac, Horizontal flame. Optional - 60 deg C or 80 deg C Oil.
√ Conductor: 32 AWG - 16 AWG, Solid or Stranded.
√ Insulation: Extruded PVC, 15 mils minimum average thickness, 13 mils minimum thickness at any point.
Conductor | Insulation | Max Resistance (Ω/km, 20°C, DC) | |||
AWG | No./mm | Nom.Dia.(mm) | Nom.Thick.(mm) | Nom.Dia.(mm) | |
26 | 1/0.404 | 0.4 | 0.4 | 1.2 | 142.79 |
7/0.16 | 0.48 | 0.41 | 1.3 | 148.94 | |
24 | 1/0.511 | 0.51 | 0.41 | 1.33 | 89.39 |
11/0.16 | 0.61 | 0.41 | 1.43 | 93.25 | |
22 | 1/0.643 | 0.64 | 0.41 | 1.46 | 54.3 |
17/0.16 | 0.76 | 0.41 | 1.58 | 55 | |
20 | 1/0.813 | 0.81 | 0.41 | 1.65 | 33.9 |
26/0.16 | 0.94 | 0.41 | 1.76 | 34.6 | |
18 | 1/1.024 | 1.02 | 0.41 | 1.85 | 21.4 |
41/0.16 | 1.18 | 0.41 | 2 | 21.8 | |
16 | 26/0.254 | 1.49 | 0.41 | 2.32 | 14.64 |
